TIP36C Transistor BJT PNP 100V 25A
$47.41 +IVA
Especificaciones técnicas:
Type | PNP |
Categoría del producto | Bipolar Power |
Configuration | Single |
Number of Elements per Chip | 1 |
Maximum Collector Base Voltage (V) | 100 |
Maximum Collector-Emitter Voltage (V) | 100 |
Maximum Emitter Base Voltage (V) | 5 |
Maximum Collector-Emitter Saturation Voltage (V) | 1.8@1.5A@15A|4@5A@25A |
Maximum DC Collector Current (A) | 25 |
Minimum DC Current Gain | 25@1A@10V|10@15A@4V |
Maximum Power Dissipation (mW) | 125000 |
Maximum Transition Frequency (MHz) | 3(Min) |
Minimum Operating Temperature (°C) | -65 |
Maximum Operating Temperature (°C) | 150 |
Packaging | Tube |
AEC Qualified | No |
Standard Package Name | TO-247 |
